1.This series primarily used with construction and mining required Ø138mm DTH drill, bolting rig, various hand held drill machines, drifters, blasting equipment and various air source requirement.
2.All new designed air inlet valve and optimized air control system with less control parts and less breakdown possibilities for engine to easily start at idle.
3.All with EU3A compatible engines or IP55 motors.
Compressor technical specifications
1
Model
S125D+
2
Descriptions
Diesel engine driven screw air compressor
3
Rated F.A.D
m³/min
36
4
Rated working pressure
bar
30
5
Oil content
PPM
£3
6
Discharge air temperature
℃
100℃
7
Compressor oil capacity
L
100
8
Air Storage tank capacity
L
160
9
Compression stage
级
2
10
Transmission type
Coupling direct dri...
Application
Model
F.A.D
Rated Pressure
Motor Power
Air End
Motor Protection Class
Weight
45SCF+ -8B
7.5 m3 /min
8 bar
45kW
Single Stage Compression
IP55
920 kg
55SCF+ -8B
9.8 m³/min
8 bar
55 kW
1,040 kg
75SCF+ -8B
13.2 m³/min
8 bar
75 kW
1,585 kg
90SCF+ -8B
15.5 m³/min
8 bar
90 kW
1,695 kg
110SCF+ -8B
20 m³/min
8 bar
110 kW
1,955 kg
132SCF+ -8B
24 m³/min
8 bar
132 kW
2,065 kg
90SCFT+ -8A
20 m³/min
8 bar
90 kW
T...
